Hylele UFO High Bay Light Quick and Easy Installation Tutorial

Why Hylele UFO High Bay Light Installation Stands Out: Quick & Hassle-Free

• Lightweight Design: Most Hylele UFO models weigh 5-8kg (11-17.6lbs), significantly lighter than bulky HPS/MH lamps (10-15kg). This reduces the need for heavy lifting equipment and simplifies ceiling mounting.
• Universal Mounting Options: Comes with built-in brackets for ceiling suspension (chain/cable), surface mounting (direct ceiling), and wall mounting—adapting to warehouses, factories, and sports halls alike.
• Plug-and-Play Wiring: Color-coded wires and a pre-installed terminal block eliminate confusion, making electrical connections fast and error-free.
• All-Inclusive Hardware Kit: Each lamp includes screws, anchors, chains (for suspension), and wire nuts—no need to purchase additional parts.

Pre-Installation Preparation: Safety First & Tools You’ll Need

a. Safety Precautions

• Turn Off Power: Locate the circuit breaker for the installation area and switch it off. Use a voltage tester to confirm no electricity is flowing to the wiring.
• Use Proper PPE: Wear non-slip gloves, safety glasses, and a hard hat—especially when working at heights.
• Secure Ladders/Platforms: Use a stable step ladder or aerial platform. Never stand on the top two rungs of a ladder.
• Check Weight Capacity: Ensure the ceiling or mounting surface can support the lamp’s weight (add 20% extra for safety).

b. Required Tools

• Drill with Phillips-head bit and masonry bit (for concrete ceilings).
• Screwdriver set (Phillips and flat-head).
• Voltage tester.
• Tape measure and pencil (for marking mounting points).
• Wire strippers (if adjusting wire length).
• Level (to ensure the lamp is straight).

c. Unbox & Inspect the Lamp

Step-by-Step Installation: 3 Common Mounting Methods

Method 1: Ceiling Suspension (Most Popular for Warehouses/Factory Floors)

1. Mark Suspension Points: Use a tape measure to determine the desired distance between lamps (typically 3-5 meters apart for uniform coverage). Mark two points on the ceiling, 15-20cm apart (matching the lamp’s suspension brackets).
2. Install Ceiling Hooks: Drill pilot holes at the marked points. Insert expansion anchors (included in the kit) into the holes, then screw in the ceiling hooks until they’re tight.
3. Attach Chains to the Lamp: Take the included chains and connect one end to each suspension bracket on the top of the UFO lamp. Use the locking clips (in the hardware kit) to secure the chains.
4. Hang the Lamp: Lift the lamp (use a ladder or helper for safety) and hook the other end of the chains onto the ceiling hooks. Adjust the chain length to the desired height (ensure all lamps are at the same height for uniformity).
5. Connect Wiring: Remove the lamp’s wiring cover (twist or unscrew it). You’ll see three color-coded wires: brown (live), blue (neutral), and green/yellow (ground). Connect these to the corresponding wires in the ceiling (match colors). Use wire nuts to secure the connections, then tuck the wires into the lamp’s wiring compartment and replace the cover.

Method 2: Surface Mounting (For Low Ceilings & Sports Halls)

1. Mark Mounting Holes: Place the lamp’s mounting base against the ceiling at the desired location. Use a pencil to mark the four screw holes on the ceiling.
2. Drill Pilot Holes: Drill holes at the marked points, then insert expansion anchors (if mounting on concrete) or wood screws (if mounting on wood).
3. Secure the Lamp: Align the lamp’s mounting base with the holes, then drive the included screws through the base into the anchors/screws. Tighten until the lamp is firmly attached (use a level to ensure it’s straight).
4. Wire Connection: Follow Step 5 from Method 1 (color-coded wiring) to connect the lamp to the ceiling power supply.

Method 3: Wall Mounting (For Tunnels & Narrow Spaces)

1. Install Wall Bracket: Attach the optional wall mounting bracket (available from Hylele) to the wall using expansion anchors and screws. Ensure the bracket is level and secure.
2. Mount the Lamp: Slide the UFO lamp’s mounting base onto the wall bracket until it clicks into place. Use a set screw to lock it in position.
3. Wire Connection: Run the power cable through the bracket’s cable management hole, then connect the wires as in Method 1.

Post-Installation Check: Ensure Safe & Proper Operation

• Turn On Power: Switch the circuit breaker back on. The lamp should light up immediately—if not, turn off power and double-check the wiring connections.
• Check Stability: Gently tug the lamp (or chains) to ensure it’s securely mounted. There should be no wobbling or loose parts.
• Verify Illumination: Stand at ground level and check that the light is uniform, with no dark spots. Adjust the chain length (if suspended) if needed.
• Test Optional Features: If your model has dimming or motion sensors, test these functions to ensure they work as expected.

Troubleshooting Common Installation Issues

• Lamp doesn’t turn on: Check if the circuit breaker is on; verify wiring connections (ensure no loose wires or mismatched colors); test the voltage with a tester.
• Lamp is flickering: Loose wiring is the most common cause—recheck wire nuts and connections. If flickering persists, the driver may be faulty (contact Hylele support).
• Mounting is unstable: Tighten screws/anchors; ensure the ceiling/wall can support the lamp’s weight (add additional anchors if needed).

Conclusion: Install Hylele UFO High Bay Lights in Minutes, Not Hours
